WS-601SS5 Tipping Bucket Rain Gauge Stainless Steel High Precision Meteorological Hydrological Rainfall Sensor
$50.00
WS-601SS5 Tipping Bucket Rain Gauge Stainless Steel High Precision Meteorological Hydrological Rainfall Sensor
Summary
WS-601SS5 Tipping Bucket Rain Gauge Stainless Steel High Precision Meteorological Hydrological Rainfall Sensor by BGT. Category: Precipitation Sensors. Key specs: output Reed switch,5pulse/mm (MaxDC24V,100mA); RS485(Optional) | measuring range 0~4mm/min, workable 8mm/min | accuracy ±≤ 2%(≤ 0.4mm/min); ±≤ 4% (≤4mm/min). Origin: Guangdong, China. Price from US $50.00 per piece.
Key Specifications
- Brand: BGT
- Model: WS-601SS5
- Output: Reed switch,5pulse/mm (MaxDC24V,100mA); RS485(Optional)
- Measuring Range: 0~4mm/min, workable 8mm/min
- Accuracy: ±≤ 2%(≤ 0.4mm/min); ±≤ 4% (≤4mm/min)
- Resolution: 0.5mm
- Power Supply: Pulse: MaxDC24V,100mA; RS485(Optional): DC 7-24V
- Place of origin: Guangdong, China
FAQ
What output or interface does WS-601SS5 use?
WS-601SS5 output / interface: Reed switch,5pulse/mm (MaxDC24V,100mA); RS485(Optional).
What is the measuring range of WS-601SS5?
The measuring range of WS-601SS5 is 0~4mm/min, workable 8mm/min.
What power supply does WS-601SS5 need?
WS-601SS5 power supply: Pulse: MaxDC24V,100mA; RS485(Optional): DC 7-24V.
How do I order or request a quote?
Contact us via WhatsApp +86 18565278999 or email sale@shopsssss.com / info@abbme.com. We quote bulk orders, OEM customization and volume pricing.
Price
Reference price: US $50.00 - $500.00 per piece (depends on quantity and configuration).
Key Attributes
Industry-specific attributes
| Mounting Type | Rod installation |
| Manufacturer Part Number | WS-601SS5 |
| Type | 0.5mm Stainless Steel Tipping Bucket Rain Gauge |
| Brand Name | BGT |
| Usage | gather and and measure the amount of liquid |
| Sensor Type | Moisture |
Other attributes
| Description | WS-601SS5 Tipping Bucket Rain Gauge |
| Place of Origin | Guangdong, China |
| Theory | used by meteorologists and hydrologists |
| Resolution | 0.5mm |
| Accuracy | ±≤ 2%(≤ 0.4mm/min); ±≤ 4% (≤4mm/min) |
| Measuring Range | 0~4mm/min, workable 8mm/min |
| Bucket Material | ABS UV Stabilished Plastic |
| Base Material | Polished 304 Stainless Steel &Aluminum |
| Inner Diameter | 200mm/8inch ±0.3% |
| Acute angle of cutting edge | 40~45° |
| Working Environment | -10~50℃ , 0%~95%RH |
| Power Supply | Pulse: MaxDC24V,100mA; RS485(Optional): DC 7-24V |
| Output | Reed switch,5pulse/mm (MaxDC24V,100mA); RS485(Optional) |
Product Description
Product Description1
0.5mm Stainless Steel Tipping Bucket Rain Gauge
The model WS-601SS5 Tipping Bucket Rain Gauge is an instrument used by meteorologists and hydrologists to gather and and measure the amount of liquid precipitation over an area in a predefined period of time
